System And Components
219-9929 IGNITION GP-GAS ENGINE (CHG -06 THRU -08)Type 3
Group No: 219-9929
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D1326 | 1 LOCKWASHER | 2 | |
| 9X7688 | 2 SEAL-O-RING | 8 | |
| 1270594 | 3 WIRE AS-GROUND | 1 | |
| 3505226 | 4 COVER (LIFTER GUIDE) | 8 | |
| 1663796 | 5 TUBE AS | 8 | |
| 2136288 | 6 BRACKET | 4 | |
| 2149421 | 7 BRACKET AS | 3 | |
| 3103180 | 8 TRANSFORMER GP-IGNITION | 8 | |
| 0S0509 | 9 BOLT (3/8-16X0.75-IN) | 2 | |
| 0S1571 | 10 BOLT (3/8-16X1.75-IN) | 31 | |
| 0S1594 | 11 BOLT (3/8-16X1-IN) | 14 | |
| 1948518 | 12 SPARK PLUG | 8 | |
| 9Y6792 | GASKET-SPARK PLUG | 1 | |
| 2199946 | 13 HARNESS AS-ENGINE (IGNITION) | 1 | |
| 4G2544 | CONNECTOR-PLUG | 8 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 16 | |
| 9X4813 | RECEPTACLE AS-CONNECTOR (3-PIN) | 4 | |
| 9X4814 | RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 2074556 | CONDUIT AS | 1 | |
| 2192587 | CONDUIT AS | 8 | |
| 3248782 | 14 SEAL | 8 | |
| 3V3308 | 15 WASHER-HARD (10.2X20.5X2.5-MM THK) | 32 | |
| 4B3388 | 16 BOLT (5/16-18X1.125-IN) | 32 | |
| 6V3830 | 17 SEAL-O-RING | 8 | |
| 6V3834 | 18 SEAL-O-RING | 8 | |
| 9L9132 | 19 WASHER-HARD (10.2X25.5X2.5-MM THK) | 15 | |
| 9M1974 | 20 WASHER-HARD (8.8X16X2-MM THK) | 32 |
