System And Components
219-9926 SENSOR GP-COMBUSTION (CHG -03 THRU -07)Type 2
Group No: 219-9926
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7H3937 | 1 LOCKWASHER | 2 | |
| 7W6333 | 2 SPACER (10.5X20X10.7-MM THK) | 1 | |
| 9X3495 | 3 CLIP AS | 8 | |
| 1160118 | 4 CLIP | 1 | |
| 1162649 | 5 SENSOR GP-TEMPERATURE (THERMOCOUPLE)(TURBOCHARGER INLET) | 1 | |
| 1162649 | 5A SENSOR GP-TEMPERATURE (THERMOCOUPLE)(TURBOCHARGER OUTLET) | 1 | |
| 1270594 | 6 WIRE AS-GROUND | 1 | |
| 1288831 | 7 BRACKET | 1 | |
| 1364605 | 8 EXTENSION AS | 8 | |
| 2428988 | 9 CONTROL GP-ELECTRONIC (INTEGRATED COMBUSTION SENSING) | 1 | |
| 1416380 | 10 MOUNT-FLEXIBLE | 4 | |
| 1520807 | 11 SENSOR GP-TEMPERATURE (THERMOCOUPLE) | 8 | |
| 1593219 | 12 SENSOR-COMBUSTION | 8 | |
| 1083515 | GASKET-PLUG | 1 | |
| 1884926 | 13 CONNECTOR AS | 8 | |
| 1980113 | 14 BRACKET AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 4 | |
| 1980114 | 15 PLATE | 1 | |
| 2136287 | 16 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 2136302 | 17 BRACKET | 1 | |
| 2199939 | 18 HARNESS AS-SENSOR (THERMOCOUPLE) | 1 | |
| 1762943 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 2715584 | 19 CLIP | 16 | |
| 2774765 | 20 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 2774766 | 21 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 2774767 | 22 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 2774768 | 23 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 2774769 | 24 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 2774771 | 25 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 2774772 | 26 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 2774773 | 27 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 1893769 | SEAL-O-RING | 1 | |
| 0L2070 | 28 BOLT (3/8-16X2.25-IN) | 3 | |
| 0S1615 | 29 BOLT (1/4-20X0.75-IN) | 4 | |
| 0T0102 | 30 BOLT (3/8-16X0.625-IN) | 2 | |
| 1046202 | 31 CLIP (LADDER) | 1 | |
| 1255356 | 32 DISC-INSULATOR | 16 | |
| 3B1915 | 33 BOLT (3/8-16X1.375-IN) | 2 | |
| 3V3308 | 34 WASHER-HARD (10.2X20.5X2.5-MM THK) | 15 | |
| 4F4879 | 35 BOLT (3/8-16X0.5-IN) | 1 | |
| 4P7581 | 36 CLIP (LADDER) | 8 | |
| 4P8134 | 37 CLIP (LADDER) | 1 | |
| 5P0537 | 38 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P9297 | 39 CLIP (LOOP) | 8 | |
| 5S0003 | 40 NUT (5/16-18-THD) | 8 | |
| 6B5072 | 41 ADAPTER | 1 | |
| 6V2686 | 42 CLIP | 8 | |
| 6V5050 | 43 SEAL-O-RING | 8 | |
| 9L9132 | 44 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9M1974 | 45 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9X6772 | 46 STRAP-CABLE | 54 | |
| 4P7582 | 47 CLIP (LADDER) | 1 | |
| 4D1326 | 48 LOCKWASHER | 1 | |
| 2264813 | KIT-FASTENER | 1 |
