System And Components
219-9926 SENSOR GP-COMBUSTION (CHG -08 THRU -10)Type 3
Group No: 219-9926
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 7 | |
| 4D1326 | 2 LOCKWASHER | 1 | |
| 5N2126 | 3 CONNECTOR (THERMOCOUPLE) | 1 | |
| 7H3937 | 4 LOCKWASHER | 1 | |
| 0910081 | 5 SPACER (10.5X20X10-MM THK) | 1 | |
| 1160118 | 7 CLIP | 1 | |
| 1270594 | 8 WIRE AS-GROUND | 1 | |
| 1288831 | 9 BRACKET | 1 | |
| 1364605 | 10 EXTENSION AS | 8 | |
| 2428988 | 11 CONTROL GP-ELECTRONIC (INTEGRATED COMBUSTION SENSING) | 1 | |
| 1416380 | 12 MOUNT-FLEXIBLE | 4 | |
| 3832984 | 13 SENSOR GP-TEMPERATURE (THERMOCOUPLE) | 8 | |
| 5923073 | SENSOR GP-TEMPERATURE (THERMOCOUPLE) | 1 | |
| 1593219 | 14 SENSOR-COMBUSTION | 8 | |
| 1083515 | GASKET-PLUG | 1 | |
| 1884926 | 15 CONNECTOR AS | 8 | |
| 1980113 | 16 BRACKET AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 4 | |
| 1980114 | 17 PLATE | 1 | |
| 2136287 | 18 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 2136302 | 19 BRACKET | 1 | |
| 3393559 | 20 HARNESS AS-SENSOR (THERMOCOUPLE) | 1 | |
| 8T6342 | TUBE-HEAT SHRINK (3.2-MM DIA)(40-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 20 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(50-CM) | ||
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1762943 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 2830055 | ADAPTER-CONNECTOR | 16 | |
| 2975475 | PLUG AS-CONNECTOR (2-PIN) | 8 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 2715584 | 21 CLIP | 16 | |
| 3149494 | 22 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 3149495 | 23 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 3149496 | 24 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 3149497 | 25 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 3149498 | 26 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 3149499 | 27 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 3149500 | 28 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 3149501 | 29 CABLE AS (COMBUSTION SENSOR) | 1 | |
| 1893769 | SEAL-O-RING | ||
| 3104795 | 30 SENSOR GP-TEMPERATURE (TURBOCHARGER OUTLET) | 1 | |
| 3104796 | 31 SENSOR GP-TEMPERATURE (TURBOCHARGER INLET) | 1 | |
| 0L2070 | 32 BOLT (3/8-16X2.25-IN) | 3 | |
| 0S1615 | 33 BOLT (1/4-20X0.75-IN) | 4 | |
| 0T0102 | 34 BOLT (3/8-16X0.625-IN) | 2 | |
| 1046202 | 35 CLIP (LADDER) | 1 | |
| 1255356 | 36 DISC-INSULATOR | 16 | |
| 3B1915 | 37 BOLT (3/8-16X1.375-IN) | 2 | |
| 3V3308 | 38 WASHER-HARD (10.2X20.5X2.5-MM THK) | 15 | |
| 4F4879 | 39 BOLT (3/8-16X0.5-IN) | 1 | |
| 4P7581 | 40 CLIP (LADDER) | 16 | |
| 4P7582 | 41 CLIP (LADDER) | 1 | |
| 4P8134 | 42 CLIP (LADDER) | 1 | |
| 5P0537 | 43 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P9297 | 44 CLIP (LOOP) | 8 | |
| 5S0003 | 45 NUT (5/16-18-THD) | 8 | |
| 6V2686 | 46 CLIP | 8 | |
| 6V5050 | 47 SEAL-O-RING | 8 | |
| 9L9132 | 48 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9M1974 | 49 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9X6772 | 50 STRAP-CABLE | 58 | |
| 6B5072 | 52 ADAPTER | 1 | |
| 2264813 | KIT-FASTENER | 1 |
