System And Components
131-0530 LINES GP-WATER (CHG -03, -04)TWO STAGE AFTERCOOLER
Group No: 131-0530
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1A2161 | 1 SPACER (0.4X0.875X0.381-IN) | 4 | |
| 2N1117 | 2 CLIP | 2 | |
| 4P9224 | 3 COVER | 1 | |
| 5R9779 | 4 GASKET | 4 | |
| 7W3269 | 5 GASKET | 5 | |
| 7W3271 | 6 COVER | 1 | |
| 7W6092 | 7 HOUSING | 1 | |
| 7W9813 | 8 ORIFICE | 1 | |
| 8T6765 | 9 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1074862 | 10 PLATE | 2 | |
| 1282840 | 11 BRACKET AS | 1 | |
| 1347427 | 12 TUBE AS | 1 | |
| 1347428 | 13 TUBE AS | 1 | |
| 1347429 | 14 TUBE AS | 1 | |
| 1347430 | 15 TUBE AS | 1 | |
| 1543722 | 16 FLANGE | 1 | |
| 0S1571 | 17 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 18 BOLT (3/8-16X1.25-IN) | 8 | |
| 0S1589 | 19 BOLT (5/8-11X1.75-IN) | 12 | |
| 0S1590 | 20 BOLT (3/8-16X2-IN) | 1 | |
| 0S1591 | 21 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 22 BOLT (3/8-16X1-IN) | 6 | |
| 0T0573 | 23 BOLT (3/8-16X2.75-IN) | 4 | |
| 3B1915 | 24 BOLT (3/8-16X1.375-IN) | 1 | |
| 3V3308 | 25 WASHER-HARD (10.2X20.5X2.5-MM THK) | 34 | |
| 4B4043 | 26 BOLT (5/8-11X1.375-IN) | 4 | |
| 5P8247 | 27 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 6V5066 | 28 SEAL-O-RING | 1 | |
| 6V5504 | 29 SEAL-O-RING | 1 | |
| 8T6762 | 30 PLUG-PIPE (1/2-14-THD) | 8 | |
| 9S8752 | 31 NUT-FULL (3/8-16-THD) | 8 | |
| 9X2646 | 32 CLIP (SLOT) | 1 | |
| 9X2647 | 33 CLIP (TAB) | 1 |
