206-6539 BYPASS GP-EXHAUST -WASTEGATE (CHG -08)

Group No: 206-6539

Part Number	Part Name	Qty
1S3584	1 NUT-FULL (3/8-24 LH-THD)	1
6B6684	2 NUT-FULL (1/2-20-THD)	1
4F2753	3 LOCKNUT	1
4P0394	4 LEVER	1
5L3291	5 BEARING AS-BALL	2
5P9960	6 BOLT (1/4-20X0.75-IN)	2
6V1943	7 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN)	2
7E0701	8 GASKET	6
8C6971	9 ROD END	1
8C7321	10 ROD END	1
8H3390	11 NUT-FULL (1-1/2-12-THD)	1
8M2295	12 BOLT (3/8-16X1.625-IN)	2
1021694	13 PLATE	1
1023457	14 COVER	1
1026309	15 WASHER-THRUST	1
1026311	16 STOP	1
1108314	17 WASHER (10.3X18.3X2.66-MM THK)	4
1195927	18 SHAFT	1
1195931	19 SPACER	1
1275154	20 SHAFT	1
1338501	21 COVER AS	1
1440605	22 ADAPTER-EXHAUST	1
1440621	23 GASKET	2
1468381	24 HOUSING AS (WASTEGATE)	1
1195929	BUSHING	2
1763583	25 GUARD	2
1763587	26 CLEVIS	1
1841613	27 ELBOW-EXHAUST	2
1845290	28 GASKET	2
1846375	29 ADAPTER-EXHAUST	1
1846380	30 MANIFOLD-EXHAUST	1
1937879	31 BOOT	1
3670050	32 BRACKET AS	1
3718685	33 ROD	1
2118175	34 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC)	1
2224718	35 BELLOWS AS	2
0S1571	36 BOLT (3/8-16X1.75-IN)	8
0S1588	37 BOLT (3/8-16X1.25-IN)	8
0S1590	38 BOLT (3/8-16X2-IN)	1
1190746	39 PLUG-PIPE	8
1F7958	40 NUT-FULL (1/2-13-THD)	26
4D4065	41 ROD END	1
4D3512	42 ROD END	1
2N2766	43 LOCKNUT (3/8-16-THD)	36
3H7654	45 WASHER-HARD (13.5X22.5X3-MM THK)	48
3V3308	46 WASHER-HARD (10.2X20.5X2.5-MM THK)	26
5H2532	47 KEY-WOODRUFF	3
6V6753	48 BOLT-HIGH TEMPERATURE (3/8-16X1.375-IN)	1
7L6443	49 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN)	34
8C8491	50 WASHER-HARD (10.2X22X3-MM THK)	72
8C8589	51 BOLT-HIGH TEMPERATURE (1/2-13X2.25-IN)	24
8M9024	52 WASHER-HARD (10.2X22.5X5-MM THK)	1
9S8752	53 NUT-FULL (3/8-16-THD)	11
3W2647	54 SPACER (13.5X30X10-MM THK)	1
5P7128	55 BOLT-HIGH TEMPERATURE (3/8-16X2-IN)	2
1A1460	56 BOLT (1/2-13X2-IN)	2
0S1591	57 BOLT (3/8-16X1.5-IN)	2
3718686	58 LEVER	2
5P8245	59 WASHER-HARD (13.5X25.5X3-MM THK)	6
4D4088	60 NUT-JAM (1/2-20-THD, LH)	1
