210-5735 BYPASS GP-EXHAUST (CHG -00)WASTEGATE

Group No: 210-5735
Part NumberPart NameQty
1S35845 NUT-FULL (3/8-24 LH-THD)2
2N27666 LOCKNUT (3/8-16-THD)40
2W04397 GASKET2
2W43678 ADAPTER-EXHAUST1
3S27139 NUT-FULL (3/8-24-THD)2
4F275310 LOCKNUT1
4P039111 ROD1
4P039412 LEVER3
4P741313 ELBOW1
4P741414 ELBOW1
5H253215 KEY-WOODRUFF3
5L329116 BEARING AS-BALL2
5P275517 BOLT-HIGH TEMPERATURE (3/8-16X2.75-IN)4
5P996018 BOLT (1/4-20X0.75-IN)2
6V194319 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN)2
6V675320 BOLT-HIGH TEMPERATURE (3/8-16X1.375-IN)1
7E070121 GASKET6
7L644322 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN)36
7W911523 ADAPTER-EXHAUST1
7W919124 GASKET1
8C731525 ROD END1
8C732126 ROD END1
8H339027 NUT-FULL (1-1/2-12-THD)1
8M229528 BOLT (3/8-16X1.625-IN)2
039989529 ROD1
102169430 PLATE1
102345731 COVER1
102630932 WASHER-THRUST1
102631133 STOP1
110831434 WASHER (10.3X18.3X2.66-MM THK)4
118473635 SHAFT-WASTEGATE1
119592736 SHAFT1
119593037 HOUSING AS1
1195929BUSHING2
119593138 SPACER1
123571739 BELLOWS AS2
133850140 COVER AS1
141988541 BRACKET AS1
173747642 ROD END1
173747743 ROD END1
176358344 GUARD2
176358745 CLEVIS1
193787946 BOOT1
196952947 ACTUATOR GP-ELECTRONIC1
0S157148 BOLT (3/8-16X1.75-IN)6
0S158849 BOLT (3/8-16X1.25-IN)5
0S159050 BOLT (3/8-16X2-IN)4
0S159151 BOLT (3/8-16X1.5-IN)4
0S159552 BOLT (1/2-13X1.25-IN)36
119074653 PLUG-PIPE5
3V330854 WASHER-HARD (10.2X20.5X2.5-MM THK)29
5P824555 WASHER-HARD (13.5X25.5X3-MM THK)6
6V867556 BOLT (M12X1.75X35-MM)6
8C849157 WASHER-HARD (10.2X22X3-MM THK)72
8M902458 WASHER-HARD (10.2X22.5X5-MM THK)3
9S875259 NUT-FULL (3/8-16-THD)14
