210-5735 BYPASS GP-EXHAUST (CHG -06)WASTEGATE

Group No: 210-5735

Part Number	Part Name	Qty
3008579	1 BOLT (3/8-16X2.5-IN)	2
1S3584	5 NUT-FULL (3/8-24 LH-THD)	2
2N2766	6 LOCKNUT (3/8-16-THD)	40
2W0439	7 GASKET	2
2W4367	8 ADAPTER-EXHAUST	1
3S2713	9 NUT-FULL (3/8-24-THD)	2
4F2753	10 LOCKNUT	1
4P0391	11 ROD	1
4P0394	12 LEVER	3
4P7413	13 ELBOW	1
4P7414	14 ELBOW	1
5H2532	15 KEY-WOODRUFF	3
5L3291	16 BEARING AS-BALL	2
5P2755	17 BOLT-HIGH TEMPERATURE (3/8-16X2.75-IN)	2
5P9960	18 BOLT (1/4-20X0.75-IN)	2
6V1943	19 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN)	3
7E0701	21 GASKET	6
7L6443	22 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN)	36
7W9115	23 ADAPTER-EXHAUST	1
7W9191	24 GASKET	1
8C7315	25 ROD END	1
8C7321	26 ROD END	1
8H3390	27 NUT-FULL (1-1/2-12-THD)	1
8M2295	28 BOLT (3/8-16X1.625-IN)	2
0399895	29 ROD	1
1021694	30 PLATE	1
1023457	31 COVER	1
1026309	32 WASHER-THRUST	1
1026311	33 STOP	1
1108314	34 WASHER (10.3X18.3X2.66-MM THK)	4
1184736	35 SHAFT-WASTEGATE	1
5860572	36 SHAFT-WASTEGATE	1
1195930	37 HOUSING AS	1
1195929	37A BUSHING	2
1195931	38 SPACER	1
1338501	39 COVER AS	1
1419885	40 BRACKET AS	1
1763583	41 GUARD	2
1763587	42 CLEVIS	1
1937879	43 BOOT	1
2118175	44 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC)	1
2224718	45 BELLOWS AS	2
1653931	46 BOLT (3/8-16X1.75-IN)	6
1653928	47 BOLT (3/8-16-THD)	4
0S1590	48 BOLT (3/8-16X2-IN)	1
1653929	49 BOLT (3/8-16X1.5-IN)	4
0S1595	50 BOLT (1/2-13X1.25-IN)	36
1190746	51 PLUG-PIPE	5
2253769	52 ROD END	1
2253770	53 ROD END	1
3V3308	54 WASHER-HARD (10.2X20.5X2.5-MM THK)	26
5P8245	55 WASHER-HARD (13.5X25.5X3-MM THK)	6
6V8675	56 BOLT (M12X1.75X35-MM)	6
8C8491	57 WASHER-HARD (10.2X22X3-MM THK)	72
8M9024	58 WASHER-HARD (10.2X22.5X5-MM THK)	3
9S8752	59 NUT-FULL (3/8-16-THD)	11
3512247	61 BOLT (3/8-16X1.5-IN)	4
