206-6540 LINES GP-AIR (CHG -00)AIR INLET CHOKE

Group No: 206-6540
Part NumberPart NameQty
1S35841 NUT-FULL (3/8-24 LH-THD)2
2W47662 GASKET1
3S27133 NUT-FULL (3/8-24-THD)2
4P03904 ROD1
4P03945 LEVER3
5H25326 KEY-WOODRUFF3
5L32917 BEARING AS-BALL2
6I07338 HOUSING AS1
6V5041SEAL-LIP TYPE2
1611201BUSHING2
6I16419 PLATE1
6I164210 PLATE1
6I164311 COVER AS1
6I164412 WASHER-THRUST1
6I164513 SHAFT1
7C845414 PLATE-BUTTERFLY1
7W634015 GASKET2
8C731516 ROD END2
8C732117 ROD END2
8H339018 NUT-FULL (1-1/2-12-THD)1
032176819 SETSCREW (3/8-16-THD)1
118384220 BRACKET AS1
118384321 SHAFT1
145003922 BRACKET AS1
145004023 BRACKET AS1
145004124 ROD1
176358325 GUARD2
176358726 CLEVIS1
180840827 ADAPTER1
183723228 BELLOWS AS2
184637929 HOUSING1
193787930 BOOT1
196952931 ACTUATOR GP-ELECTRONIC1
197812032 GASKET4
206656933 PLATE1
031508534 BOLT-LOCKING (1/4-20X1-IN)4
0S156635 BOLT (5/8-11X1.5-IN)12
0S157136 BOLT (3/8-16X1.75-IN)22
0S158737 BOLT (1/2-13X1.75-IN)1
0S158838 BOLT (3/8-16X1.25-IN)12
0S158939 BOLT (5/8-11X1.75-IN)10
0S159040 BOLT (3/8-16X2-IN)5
0S159141 BOLT (3/8-16X1.5-IN)12
0S159442 BOLT (3/8-16X1-IN)6
1A957943 BOLT (5/16-18X1.5-IN)1
1F795844 NUT-FULL (1/2-13-THD)1
1J866845 STUD-TAPERLOCK (3/8-16X1.97-IN)4
3V330846 WASHER-HARD (10.2X20.5X2.5-MM THK)76
5P824547 WASHER-HARD (13.5X25.5X3-MM THK)1
5P824748 WASHER-HARD (17X32X3.5-MM THK)24
5S000349 NUT (5/16-18-THD)1
6V504950 SEAL-O-RING2
8B799751 BOLT-SOCKET HEAD (1/2-13X2-IN)2
8M902452 WASHER-HARD (10.2X22.5X5-MM THK)3
9S419153 PLUG (9/16-18-THD)2
9S875254 NUT-FULL (3/8-16-THD)21
