230-3215 LINES GP-AIR (CHG -00 THRU -02)

Group No: 230-3215

Part Number	Part Name	Qty
1S3584	1 NUT-FULL (3/8-24 LH-THD)	2
2W4766	2 GASKET	1
3S2713	3 NUT-FULL (3/8-24-THD)	2
4P0394	4 LEVER	3
4W7392	5 PIPE	2
4W7515	6 ELBOW (LH)	1
4W7516	7 ELBOW (RH)	1
5H2532	8 KEY-WOODRUFF	3
5L3291	9 BEARING AS-BALL	2
6I0733	10 HOUSING AS	1
6V5041	SEAL-LIP TYPE	2
1611201	BUSHING	2
6I1641	11 PLATE	1
6I1642	12 PLATE	1
6I1643	13 COVER AS	1
6I1644	14 WASHER-THRUST	1
7C8454	15 PLATE-BUTTERFLY	1
7W6340	16 GASKET	2
8C7315	17 ROD END	2
8C7321	18 ROD END	2
8H3390	19 NUT-FULL (1-1/2-12-THD)	1
0321768	20 SETSCREW (3/8-16-THD)	1
1183842	21 BRACKET AS	1
1183843	22 SHAFT	1
1233856	23 ADAPTER	1
1249765	24 ADAPTER	1
1347955	25 BRACKET AS	1
1349441	26 SHAFT	1
1450039	27 BRACKET AS	1
1450040	28 BRACKET AS	1
1450041	29 ROD	1
1475092	30 ROD	1
1763583	31 GUARD	2
1763587	32 CLEVIS	1
1937879	33 BOOT	1
2066569	34 PLATE	1
2118175	35 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC)	1
0315085	36 BOLT-LOCKING (1/4-20X1-IN)	4
0S1571	37 BOLT (3/8-16X1.75-IN)	21
0S1587	38 BOLT (1/2-13X1.75-IN)	3
0S1588	39 BOLT (3/8-16X1.25-IN)	14
0S1590	40 BOLT (3/8-16X2-IN)	3
0S1591	41 BOLT (3/8-16X1.5-IN)	17
0S1594	42 BOLT (3/8-16X1-IN)	6
0T0573	43 BOLT (3/8-16X2.75-IN)	1
1A1460	44 BOLT (1/2-13X2-IN)	10
1A9579	45 BOLT (5/16-18X1.5-IN)	1
1F7958	46 NUT-FULL (1/2-13-THD)	10
3V3308	47 WASHER-HARD (10.2X20.5X2.5-MM THK)	77
5P8245	48 WASHER-HARD (13.5X25.5X3-MM THK)	23
5S0003	49 NUT (5/16-18-THD)	1
6V5049	50 SEAL-O-RING	2
6V5095	51 SEAL-O-RING	8
6V5102	52 SEAL-O-RING	2
8M9024	53 WASHER-HARD (10.2X22.5X5-MM THK)	3
9S4191	54 PLUG (9/16-18-THD)	2
9S8752	55 NUT-FULL (3/8-16-THD)	15
3512247	56 BOLT (3/8-16X1.5-IN)	4
