Assembly
100%

195-6245 SENSOR GP-COMBUSTION (CHG -16)

Group No: 195-6245
Part NumberPart NameQty
13646051 EXTENSION AS12
3S20932 STRAP-CABLE9
5N21263 CONNECTOR (THERMOCOUPLE)2
7G12394 SPACER (10.5X19X4.5-MM THK)1
7K11815 STRAP-CABLE11
9X67726 STRAP-CABLE79
11601187 CLIP3
12888318 BRACKET1
15932199 SENSOR-COMBUSTION (WIRING)12
1083515GASKET-PLUG1
188492610 CONNECTOR AS12
192432911 BRACKET10
234589512 CAP4
314948613 CABLE AS (COMBUSTION SENSOR)2
314948714 CABLE AS (COMBUSTION SENSOR)2
314948815 CABLE AS (COMBUSTION SENSOR)2
314949016 CABLE AS (COMBUSTION SENSOR)2
314949117 CABLE AS (COMBUSTION SENSOR)2
314949218 CABLE AS (COMBUSTION SENSOR)2
1893769SEAL-O-RING1
324788219 MOUNTING GP-CONTROL2
383298420 SENSOR GP-TEMPERATURE (THERMOCOUPLE)12
5923073SENSOR GP-TEMPERATURE (THERMOCOUPLE)1
339356021 HARNESS AS-SENSOR (COMBUSTION, TEMP, LH)1
339356122 HARNESS AS-SENSOR (COMBUSTION, TEMP, RH)1
550665323 SENSOR GP-TEMPERATURE (TURBOCHARGER INLET)2
550666524 SENSOR GP-TEMPERATURE (TURBOCHARGER OUTLET)2
091008125 SPACER (10.5X20X10-MM THK)1
0L207026 BOLT (3/8-16X2.25-IN)1
165393127 BOLT (3/8-16X1.75-IN)47
165392828 BOLT (3/8-16-THD)1
0S159429 BOLT (3/8-16X1-IN)12
0S162030 BOLT (1/2-13X0.75-IN)2
125535631 DISC-INSULATOR24
132578932 CLIP (LADDER)11
271558433 CLIP24
3V330834 WASHER-HARD (10.2X20.5X2.5-MM THK)62
4F487935 BOLT (3/8-16X0.5-IN)1
4P742836 CLIP (LADDER)2
4P758137 CLIP (LADDER)19
4P813438 CLIP (LADDER)15
5M289439 WASHER-HARD (10.2X18.5X2.5-MM THK)2
5P824540 WASHER-HARD (13.5X25.5X3-MM THK)2
5P929741 CLIP (LOOP)6
6B507242 ADAPTER2
6V268643 CLIP (LOOP)12
6V505044 SEAL-O-RING12
9L913245 WASHER-HARD (10.2X25.5X2.5-MM THK)10
9S875246 NUT-FULL (3/8-16-THD)1
2264813KIT-FASTENER1
