System And Components
131-0525 AFTERCOOLER GP-WATER (CHG -02 THRU -08, -08D1, -08D2, -08D3)TWO STAGE
Group No: 131-0525
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W0805 | 1 COVER (CYLINDER BLOCK) | 2 | |
| 8B2026 | 2 SPACER (0.438X0.75X1.5-IN THK) | 4 | |
| 1233854 | 3 HOUSING | 1 | |
| 1233855 | 4 COVER (AFTERCOOLER) | 1 | |
| 1278177 | 5 GASKET | 2 | |
| 1301288 | 6 SEAL-INTEGRAL | 8 | |
| 1308130 | 7 CORE AS-AFTERCOOLER | 1 | |
| 1487634 | 8 PLATE | 1 | |
| 1564313 | 9 TUBE AS | 1 | |
| 0L2070 | 10 BOLT (3/8-16X2.25-IN) | 64 | |
| 0S1590 | 11 BOLT (3/8-16X2-IN) | 64 | |
| 0S1594 | 12 BOLT (3/8-16X1-IN) | 26 | |
| 3B1915 | 13 BOLT (3/8-16X1.375-IN) | 1 | |
| 3V3308 | 14 WASHER-HARD (10.2X20.5X2.5-MM THK) | 111 | |
| 4B3388 | 15 BOLT (5/16-18X1.125-IN) | 28 | |
| 5K5552 | 16 BOLT-LOCKING (3/8-16X3-IN) | 84 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 128 | |
| 8L2786 | 18 SEAL-O-RING | 13 | |
| 9M1974 | 19 WASHER-HARD (8.8X16X2-MM THK) | 14 | |
| 9S4185 | 20 PLUG (3/4-16-THD) | 11 | |
| 9S8005 | 21 PLUG (3/4-16-THD) | 2 |
