373-1476 BYPASS GP-EXHAUST -WASTEGATE (CHG -04)Type 2

Group No: 373-1476

Part Number	Part Name	Qty
3W2647	1 SPACER (13.5X30X10-MM THK)	1
4F2753	2 LOCKNUT	1
7E0701	3 GASKET	6
1021694	4 PLATE	1
1023457	5 COVER	1
1026309	6 WASHER-THRUST	1
1026311	7 STOP	1
5860572	8 SHAFT-WASTEGATE	1
1195931	9 SPACER	1
1338501	10 COVER AS	1
1440605	11 ADAPTER-EXHAUST	1
1440621	12 GASKET	2
1468381	13 HOUSING AS (WASTEGATE)	1
1195929	13A BUSHING	2
1763583	14 GUARD	2
1841613	15 ELBOW-EXHAUST	2
1845290	16 GASKET	2
1846375	17 ADAPTER-EXHAUST	1
1846380	18 MANIFOLD-EXHAUST	1
1937879	19 BOOT	1
2224718	20 BELLOWS AS	2
3699191	21 SUPPORT	1
3718685	22 ROD	1
3718686	23 LEVER	1
3840964	24 CLEVIS	1
1653931	25 BOLT (3/8-16X1.75-IN)	1
1653929	26 BOLT (3/8-16X1.5-IN)	4
1108314	27 WASHER (10.3X18.3X2.66-MM THK)	76
1190746	28 PLUG-PIPE	8
1A1460	29 BOLT (1/2-13X2-IN)	1
1F7958	30 NUT-FULL (1/2-13-THD)	26
2118175	31 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC)	1
2M0849	32 WASHER-HARD (13.5X25.5X5-MM THK)	1
2N2766	33 LOCKNUT (3/8-16-THD)	36
3512247	34 BOLT (3/8-16X1.5-IN)	4
3H7654	35 WASHER-HARD (13.5X22.5X3-MM THK)	48
3V3308	36 WASHER-HARD (10.2X20.5X2.5-MM THK)	2
4D3512	37 ROD END	1
4D4065	38 ROD END	1
4D4088	39 NUT-JAM (1/2-20-THD, LH)	1
5H2532	40 KEY-WOODRUFF	1
5M2894	41 WASHER-HARD (10.2X18.5X2.5-MM THK)	4
5P7128	42 BOLT-HIGH TEMPERATURE (3/8-16X2-IN)	2
5P8245	43 WASHER-HARD (13.5X25.5X3-MM THK)	4
5P9960	44 BOLT (1/4-20X0.75-IN)	2
6B6684	45 NUT-FULL (1/2-20-THD)	1
6V1943	46 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN)	3
7L6443	48 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN)	34
8C8589	50 BOLT-HIGH TEMPERATURE (1/2-13X2.25-IN)	24
8H3390	51 NUT-FULL (1-1/2-12-THD)	1
8M2295	52 BOLT (3/8-16X1.625-IN)	2
9S8752	53 NUT-FULL (3/8-16-THD)	1
2B0947	54 BOLT (1/2-13X2.25-IN)	1
