Assembly
100%

228-7328 TURBOCHARGER GP (CHG -00 THRU -03)FOR USE WITH INDUSTRIAL ENGINES

Group No: 228-7328
Part NumberPart NameQty
17636112 CLAMP-BAND1
23009333 HOUSING-COMPRESSOR1
17817974 STUD (M12X1.75X65-MM)12
17817985 NUT (M12X1.75-THD)12
23009366 INSERT (TURBINE)1
21132127 HOUSING-TURBINE1
21132158 HOUSING-BEARING1
17636099 KIT-SEAL (BEARING)1
176361010 KIT-BEARING1
207611111 STUD (M12X1.75X35-MM)12
1781790CLAMP3
1781791BOLT (M12X1.75X35-MM)18
1781799BOLT (M12X1.75X25-MM)5
1781800WASHER (14X29X3-MM THK)7
1781801BOLT (M12X1.75X42.5-MM)2
2076106KIT-TURBOCHARGER SEAL1
2076109CLIP4
2076110WASHER (12.5X21X2.7-MM THK)12
2300932CARTRIDGE GP-TURBOCHARGER1
2300939INSERT1
2300937DIFFUSER1
2300938RING-NOZZLE1
