440-6257 TURBOCHARGER GP (CHG -00 THRU -02)

Group No: 440-6257
Part NumberPart NameQty
20761111 STUD (M12X1.75X35-MM)12
17817982 NUT (M12X1.75-THD)24
17636113 CLAMP-BAND (COMPRESSOR)1
17817904 CLAMP3
17817915 BOLT (M12X1.75X35-MM)18
17817976 STUD (M12X1.75X65-MM)12
17817997 BOLT (M12X1.75X25-MM)5
17818008 WASHER (14X29X3-MM THK)7
17818019 BOLT (M12X1.75X42.5-MM)2
207610910 CLIP4
207611011 WASHER (12.5X21X2.7-MM THK)12
361782112 HOUSING AS-COMPRESSOR1
230093613 INSERT (TURBINE)1
230093714 DIFFUSER1
230093915 INSERT1
230094616 RING1
262711717 HOUSING AS-TURBINE (TURBINE)1
3829185PLUG2
273210518 CARTRIDGE GP-TURBOCHARGER1
2525060PLUG2
2546769SEAL2
330783519 SHIELD AS1
364368820 RING-NOZZLE1
1763609KIT-SEAL (BEARING)1
1763610KIT-BEARING (TURBOCHARGER)1
2076106KIT-TURBOCHARGER SEAL1
