System And Components
206-5460 IGNITION GP-GAS ENGINE (CHG -06 THRU -08)Type 3
Group No: 206-5460
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B4971 | 1 SPACER (0.406X1X1-IN THK) | 1 | |
| 3S8665 | 2 CLIP (LOOP) | 1 | |
| 4D1326 | 3 LOCKWASHER | 4 | |
| 9X6772 | 4 STRAP-CABLE | 2 | |
| 9X7688 | 5 SEAL-O-RING | 16 | |
| 1270594 | 6 WIRE AS-GROUND | 2 | |
| 3505226 | 7 COVER (LIFTER GUIDE) | 16 | |
| 1663796 | 8 TUBE AS | 16 | |
| 1982938 | 9 HARNESS AS-WIRING (IGNITION, RH) | 1 | |
| 4G2544 | CONNECTOR-PLUG | 8 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 16 | |
| 9X4813 | RECEPTACLE AS-CONNECTOR (3-PIN) | 4 | |
| 9X4814 | RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 2074554 | CONDUIT AS | 8 | |
| 2074556 | CONDUIT AS | 1 | |
| 1982941 | 10 HARNESS AS-WIRING (IGNITION, LH) | 1 | |
| 4G2544 | CONNECTOR-PLUG | 8 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 16 | |
| 9X4813 | RECEPTACLE AS-CONNECTOR (3-PIN) | 4 | |
| 9X4814 | RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 2074554 | CONDUIT AS | 8 | |
| 2074555 | CONDUIT AS | 1 | |
| 3103180 | 11 TRANSFORMER GP-IGNITION | 16 | |
| 0L2070 | 12 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S0509 | 13 BOLT (3/8-16X0.75-IN) | 2 | |
| 0S1571 | 14 BOLT (3/8-16X1.75-IN) | 63 | |
| 0S1594 | 15 BOLT (3/8-16X1-IN) | 14 | |
| 1948518 | 16 SPARK PLUG (IGNITION) | 16 | |
| 9Y6792 | GASKET-SPARK PLUG | 1 | |
| 3248782 | 17 SEAL | 16 | |
| 3V3308 | 18 WASHER-HARD (10.2X20.5X2.5-MM THK) | 80 | |
| 4B3388 | 19 BOLT (5/16-18X1.125-IN) | 64 | |
| 6V3830 | 20 SEAL-O-RING | 16 | |
| 6V3834 | 21 SEAL-O-RING | 16 | |
| 9M1974 | 22 WASHER-HARD (8.8X16X2-MM THK) | 64 |
