System And Components
206-5459 SENSOR GP-COMBUSTION (CHG -14)Type 5
Group No: 206-5459
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 11 | |
| 5N2126 | 2 CONNECTOR (THERMOCOUPLE) | 2 | |
| 7G1239 | 3 SPACER (10.5X19X4.5-MM THK) | 1 | |
| 7K1181 | 4 STRAP-CABLE | 15 | |
| 9X6772 | 5 STRAP-CABLE | 104 | |
| 1160118 | 6 CLIP | 3 | |
| 1288831 | 7 BRACKET | 1 | |
| 1364605 | 8 EXTENSION AS | 16 | |
| 1593219 | 9 SENSOR-COMBUSTION | 16 | |
| 1083515 | GASKET-PLUG | 1 | |
| 1884926 | 10 CONNECTOR AS | 16 | |
| 1924329 | 11 BRACKET | 14 | |
| 3149486 | 12 CABLE AS (COMBUSTION SENSOR) | 2 | |
| 3149487 | 13 CABLE AS (COMBUSTION SENSOR) | 2 | |
| 3149488 | 14 CABLE AS (COMBUSTION SENSOR) | 2 | |
| 3149489 | 15 CABLE AS (COMBUSTION SENSOR) | 2 | |
| 3149490 | 16 CABLE AS (COMBUSTION SENSOR) | 2 | |
| 3149491 | 17 CABLE AS (COMBUSTION SENSOR) | 2 | |
| 3149492 | 18 CABLE AS (COMBUSTION SENSOR) | 2 | |
| 3149493 | 19 CABLE AS (COMBUSTION SENSOR) | 2 | |
| 1893769 | SEAL-O-RING | 1 | |
| 3247882 | 20 MOUNTING GP-CONTROL | 2 | |
| 3832984 | 21 SENSOR GP-TEMPERATURE (THERMOCOUPLE) | 16 | |
| 5923073 | SENSOR GP-TEMPERATURE (THERMOCOUPLE) | 1 | |
| 3393563 | 22 HARNESS AS-SENSOR (COMBUSTION, TEMP, RH) | 1 | |
| 3393562 | 23 HARNESS AS-SENSOR (COMBUSTION, TEMP, LH) | 1 | |
| 5506653 | 24 SENSOR GP-TEMPERATURE (TURBOCHARGER INLET) | 2 | |
| 5506665 | 25 SENSOR GP-TEMPERATURE (TURBOCHARGER OUTLET) | 2 | |
| 0910081 | 26 SPACER (10.5X20X10-MM THK) | 1 | |
| 0L2070 | 27 BOLT (3/8-16X2.25-IN) | 1 | |
| 1653931 | 28 BOLT (3/8-16X1.75-IN) | 63 | |
| 1653928 | 29 BOLT (3/8-16-THD) | 1 | |
| 0S1594 | 30 BOLT (3/8-16X1-IN) | 16 | |
| 0S1620 | 31 BOLT (1/2-13X0.75-IN) | 2 | |
| 1255356 | 32 DISC-INSULATOR | 32 | |
| 1325789 | 33 CLIP (LADDER) | 15 | |
| 2715584 | 34 CLIP | 32 | |
| 3V3308 | 35 WASHER-HARD (10.2X20.5X2.5-MM THK) | 82 | |
| 4F4879 | 36 BOLT (3/8-16X0.5-IN) | 1 | |
| 4P7428 | 37 CLIP (LADDER) | 2 | |
| 4P7581 | 38 CLIP (LADDER) | 25 | |
| 4P8134 | 39 CLIP (LADDER) | 11 | |
| 5M2894 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8245 | 41 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 5P9297 | 42 CLIP (LOOP) | 16 | |
| 6B5072 | 43 ADAPTER | 2 | |
| 6V2686 | 44 CLIP | 16 | |
| 6V5050 | 45 SEAL-O-RING | 16 | |
| 9L9132 | 46 WASHER-HARD (10.2X25.5X2.5-MM THK) | 14 | |
| 9S8752 | 47 NUT-FULL (3/8-16-THD) | 1 | |
| 2264813 | KIT-FASTENER | 1 |
