System And Components
228-8986 LINES GP-HYDRAULIC (CHG -00 THRU -02)
Group No: 228-8986
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E9277 | 1 HOSE AS | 2 | |
| 4P6814 | 2 MANIFOLD | 1 | |
| 6V9832 | 3 CAP (ORFS) | 1 | |
| 8C0569 | 4 TEE-O-RING | 2 | |
| 8C5053 | 5 ADAPTER | 1 | |
| 9C5344 | 6 SPACER (10.5X20X18-MM THK) | 2 | |
| 1216750 | 7 MANIFOLD | 1 | |
| 1386144 | 8 FILTER GP-ENGINE OIL | 1 | |
| 1386158 | 9 VALVE-CHECK | 1 | |
| 1487605 | 10 TUBE AS | 1 | |
| 1487607 | 11 TUBE AS | 1 | |
| 1487608 | 12 TUBE AS | 1 | |
| 1487609 | 13 TUBE AS | 1 | |
| 1487611 | 14 TUBE AS | 1 | |
| 1487612 | 15 TUBE AS | 1 | |
| 1487613 | 16 TUBE AS | 1 | |
| 1487616 | 17 TUBE AS | 1 | |
| 1487617 | 18 TUBE AS | 1 | |
| 1487618 | 19 TUBE AS | 1 | |
| 1487619 | 20 TUBE AS | 1 | |
| 1487620 | 21 TUBE AS | 1 | |
| 1487621 | 22 BRACKET AS | 1 | |
| 1487622 | 23 BRACKET AS | 3 | |
| 1487623 | 24 BRACKET | 3 | |
| 1487625 | 25 BRACKET AS | 1 | |
| 1487626 | 26 BRACKET | 1 | |
| 1487627 | 27 CLAMP | 2 | |
| 1487628 | 28 CLAMP | 2 | |
| 1487630 | 29 BRACKET | 1 | |
| 1487631 | 30 PLATE | 1 | |
| 1487635 | 31 MANIFOLD | 1 | |
| 1763586 | 32 VALVE AS-RELIEF | 1 | |
| 2M9780 | SEAL-O-RING | 2 | |
| 0L1143 | 33 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L1352 | 34 BOLT (3/8-16X3.25-IN) | 2 | |
| 0L2070 | 35 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S1571 | 36 BOLT (3/8-16X1.75-IN) | 5 | |
| 0S1588 | 37 BOLT (3/8-16X1.25-IN) | 16 | |
| 0S1590 | 38 BOLT (3/8-16X2-IN) | 1 | |
| 0S1594 | 39 BOLT (3/8-16X1-IN) | 13 | |
| 1A1460 | 40 BOLT (1/2-13X2-IN) | 2 | |
| 1A2029 | 41 BOLT (3/8-16X1.125-IN) | 8 | |
| 1A5183 | 42 BOLT (3/8-16X4.75-IN) | 1 | |
| 2M9780 | 43 SEAL-O-RING | 7 | |
| 3D2824 | 44 SEAL-O-RING | 11 | |
| 3J1907 | 45 SEAL-O-RING | 11 | |
| 3K0360 | 46 SEAL-O-RING | 1 | |
| 3V3308 | 47 WASHER-HARD (10.2X20.5X2.5-MM THK) | 73 | |
| 5K9660 | 48 CLIP (LOOP) | 7 | |
| 5P8245 | 49 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V8398 | 50 SEAL-O-RING | 12 | |
| 6V8629 | 51 ELBOW | 1 | |
| 6V8637 | 52 CONNECTOR | 5 | |
| 6V8638 | 53 CONNECTOR | 3 | |
| 6V8640 | 54 CONNECTOR | 2 | |
| 6V8721 | 55 ELBOW | 1 | |
| 6V8733 | 56 UNION | 2 | |
| 6V8784 | 57 TEE-FACE SEAL | 1 | |
| 6V9004 | 58 ELBOW | 1 | |
| 6V9007 | 59 ELBOW | 1 | |
| 6V9182 | 60 ELBOW | 1 | |
| 6V9746 | 61 SEAL-O-RING | 18 | |
| 6V9873 | 62 CONNECTOR | 4 | |
| 7M8485 | 63 SEAL-O-RING | 1 | |
| 8T6451 | 64 ELBOW | 1 | |
| 8T6876 | 65 ELBOW | 4 | |
| 9S4185 | 66 PLUG (3/4-16-THD) | 1 | |
| 9S4191 | 67 PLUG (9/16-18-THD) | 3 | |
| 9S8752 | 68 NUT-FULL (3/8-16-THD) | 23 |
