204-6689 BOX GP-CONTROL PANEL (CHG -00)Type 1

Group No: 204-6689

Part Number	Part Name	Qty
2V7088	1 LENS-RED (ENGINE FAILURE)	1
3E1813	2 SWITCH AS-PUSH BUTTON (LIGHTED)(PRELUBRICATION)	1
3E1814	LAMP (24-VOLT)(24-VOLT)	1
3E2149	3 SWITCH-ROTARY (ENGINE CONTROL)	1
3S2093	4 STRAP-CABLE	8
7C4910	5 SEAL	1
7D6922	6 LOCKNUT (6-32-THD)	4
7E0860	7 DIAL-CONCENTRIC (SPEED CONTROL)	1
7R3029	8 CAP-DUST	1
8L8413	9 STRAP-CABLE (WHITE)	4
9X9614	10 TERMINAL (SINGLE)	3
9X9616	11 COVER-END	2
9X9675	12 BRACKET-END	2
1096507	13 SWITCH AS-PUSH BUTTON (OPERATOR)(EMERGENCY STOP)	1
1111324	14 BLOCK-CONTACT (1-POLE)	1
1151322	15 TERMINAL (DOUBLE)	55
1152538	16 COVER-END	13
1165270	17 LAMP (24-VOLT)(RED)	1
1312639	18 WASHER (3.2X9X0.5-MM THK)	6
1314888	19 GASKET	1
1328487	20 NUT-RING	1
1535040	21 LAMP-INDICATOR (24-VOLT)	1
1535042	22 LAMP-INDICATOR (24-VOLT)	1
1560518	23 SOCKET AS	3
6V8367	LOCKWASHER	1
6V8382	NUT-HEX (11/16-27-THD)	1
1560519	24 LENS-AMBER (ALARM)	1
1560520	25 LENS-GREEN (ENGINE ON)	1
1685274	26 MODULE GP-DISPLAY	1
1748737	27 BAR-FIXED BRIDGE	1
1972691	28 STRIP-CONTACT	1
2006198	29 MODULE GP-KEYPAD (VIMS)	1
2046687	30 BOX GP-CONTROL PANEL	1
2072391	31 HARNESS AS-PANEL (CONTROL)	1
9D5421	RECEPTACLE AS-CONNECTOR (10-PIN)	1
1552255	KIT-CONNECTING PLUG (12-PIN)	1
1552258	WEDGE-PLUG LOCK (12-PIN)	1
2081028	32 FILM (CONTROL PANEL)	1
2083697	33 GASKET	1
2086049	34 TAG-IDENTIFICATION	1
0308838	35 SCREW (6-32X1-IN)	4
0335929	36 SCREW (4-40X1.25-IN)	6
1422928	37 LOCKNUT (4-40-THD)	6
4B5324	38 WASHER (3.9X9.6X1.2-MM THK)	4
8C8560	39 SCREW-LOCK (4-40X0.5-IN)	4
