System And Components
168-3640 AFTERCOOLER GP-WATERS/N ZBA1-UP
Group No: 168-3640
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N1418 | 1 GASKET-RADIATOR INLET | 2 | |
| 4W9852 | 2 HOUSING-REAR | 1 | |
| 5P7701 | 3 SEAL-O-RING | 1 | |
| 7E1823 | 4 HOUSING-FRONT | 1 | |
| 1213339 | 5 SUPPORT | 1 | |
| 1217543 | 6 PLATE | 1 | |
| 1229785 | 7 BRACKET | 1 | |
| 1525705 | 8 GASKET | 2 | |
| 1610526 | 9 AFTERCOOLER GP-RAW WATER | 1 | |
| 1721249 | 10 PLATE | 2 | |
| 0L1143 | 11 BOLT (3/8-16X2.5-IN) | 4 | |
| 0S1590 | 12 BOLT (3/8-16X2-IN) | 4 | |
| 0S1594 | 13 BOLT (3/8-16X1-IN) | 80 | |
| 1A2029 | 14 BOLT (3/8-16X1.125-IN) | 8 | |
| 3B1915 | 15 BOLT (3/8-16X1.375-IN) | 6 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 7W6492 | 17 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8L2786 | 18 SEAL-O-RING | 3 | |
| 8T6765 | 19 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9L9132 | 20 WASHER-HARD (10.2X25.5X2.5-MM THK) | 22 | |
| 9S4181 | 21 PLUG (1-5/16-12-THD) | 1 | |
| 9S4185 | 22 PLUG (3/4-16-THD) | 3 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 10 | |
| 9X6458 | 24 WASHER-HARD (10.2X22.5X3-MM THK) | 8 |
