Assembly
100%

210-9076 GUARD GP-BELTS/N R7A1-UP

Group No: 210-9076
Part NumberPart NameQty
14978641 GUARD AS-PULLEY1
1803748INSERT-THREADED (M8X1.25-THD)6
14978702 BRACKET1
17491943 BOLT (M8X1.25X16-MM)12
18882134 BRACKET AS1
1803748INSERT-THREADED (M8X1.25-THD)1
21074156 GUARD-PULLEY1
21074167 GUARD AS-PULLEY1
1803748INSERT-THREADED (M8X1.25-THD)1
21083588 GUARD AS-PULLEY1
1803748INSERT-THREADED (M8X1.25-THD)8
21100749 GUARD GP-ALTERNATOR1
4L645910 BOLT (3/8-16X2.5-IN)1
6V818812 NUT (1/2-13-THD)2
8T412114 WASHER-HARD (11X21X2.5-MM THK)6
8T413315 NUT (M10X1.5-THD)2
8T418516 BOLT (M10X1.5X50-MM)2
8T422317 WASHER-HARD (13.5X25.5X3-MM THK)4
8T489619 WASHER-HARD (10.2X18.5X2.5-MM THK)3
8T891721 BOLT (1/2-13X1.25-IN)2
8B867922 SPACER (0.406X0.75X0.44-IN THK)2
9B723723 BOLT (3/8-16X1.25-IN)2
