System And Components
205-6558 RADIATOR GPS/N R7A1-UP
Group No: 205-6558
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6L2282 | 1 PLUG-PIPE | 4 | |
| 7L2505 | 2 PLUG-PIPE | 5 | |
| 9Y5994 | 3 PLATE-WASHER | 8 | |
| 9Y5995 | 4 PLATE-WASHER | 4 | |
| 9Y6003 | 5 BRACKET-CORNER | 8 | |
| 9Y6004 | 6 BRACKET-CORNER | 8 | |
| 9Y6005 | 7 BRACKET AS-GUARD | 24 | |
| 9Y6007 | 8 WASHER-FLANGE | 48 | |
| 1102991 | 9 STRAP-COREWASHER | 8 | |
| 1102992 | 10 GASKET | 8 | |
| 1102996 | 11 BRACKET | 1 | |
| 1103002 | 12 SPACER-SPECIAL | 2 | |
| 1103004 | 13 SUPPORT | 4 | |
| 1103005 | 14 WASHER-CORE | 16 | |
| 1103006 | 15 BRACKET | 1 | |
| 1103008 | 16 GUARD | 4 | |
| 1103901 | 17 CORE | 2 | |
| 1239314 | 18 PLATE-WASHER | 4 | |
| 1239316 | 19 GAUGE-SIGHT (COOLANT LEVEL) | 2 | |
| 1239320 | 20 BRACKET | 8 | |
| 1239362 | 21 CAP-FILLER (7-PSI) | 2 | |
| 1256287 | 22 GASKET | 4 | |
| 2056564 | 23 CORE | 2 | |
| 2056568 | 24 TANK-TOP | 1 | |
| 2056573 | 25 TANK-BOTTOM | 1 | |
| 2056577 | 26 TANK AS | 1 | |
| 2056578 | 27 BRACKET | 4 | |
| 2056586 | 28 GASKET | 6 | |
| 2056587 | 29 PLATE | 1 | |
| 2056590 | 30 SHROUD | 1 | |
| 2056598 | 31 BRACKET | 2 | |
| 2056600 | 32 BRACE | 2 | |
| 2056618 | 33 LINES GP-WATER (LOWER) | 1 | |
| 2056620 | 34 LINES GP-WATER (UPPER) | 1 | |
| 2056904 | 35 GUARD AS-FAN | 2 | |
| 3H5389 | 36 U-BOLT | 1 | |
| 6V8182 | 37 NUT (3/4-10-THD) | 4 | |
| 6V8189 | 38 NUT (5/16-18-THD) | 2 | |
| 7X0365 | 39 BOLT (3/4-10X1.5-IN) | 2 | |
| 8T9311 | 40 BOLT (3/4-10X4.5-IN) | 2 |
