System And Components
265-8058 DRIVE GP-FAN -DIRECT DRIVES/N EED1-1082
Group No: 265-8058 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2M2742 | 1 PLATE-RETAINER | 1 | |
| 2P1757 | 2 HUB-FAN PULLEY | 1 | |
| 2S6150 | 3 COVER-PULLEY | 1 | |
| 3B4617 | 4 PIN-COTTER | 2 | |
| 4N8278 | 5 V-BELT SET (INCLUDES 3-BELTS) | 1 | |
| 4N8277 | V-BELT (FAN DRIVE) | 3 | |
| 5M9735 | 6 SEAL-LIP TYPE | 1 | |
| 6N3641 | 7 PULLEY-TIGHTENER | 1 | |
| 7W1399 | 8 RETAINER-SPRING | 1 | |
| 8B2327 | 9 RING-RETAINING | 1 | |
| 8N5305 | 10 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 9N6670 | 11 ARM AS | 1 | |
| 4N0955 | DOWEL | 1 | |
| 4S5367 | BUSHING AS (MOUNT) | 1 | |
| 8N4550 | SHAFT-PULLEY | 1 | |
| 1255071 | 12 SPRING | 1 | |
| 1795609 | 13 BRACKET | 1 | |
| 1795610 | 14 PULLEY-FAN | 1 | |
| 2652839 | 15 PULLEY (CRANKSHAFT) | 1 | |
| 2655827 | 16 ADAPTER | 1 | |
| 2747947 | 17 GUARD GP-BELT | 1 | |
| 4264304 | 18 BRACKET AS | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 4N0955 | DOWEL | 1 | |
| 6V2852 | DOWEL | 1 | |
| 1834277 | BRACKET | 1 | |
| 2837316 | 19 ADAPTER-FAN | 1 | |
| 2838493 | 20 PLATE | 1 | |
| 0310228 | 21 BOLT-12 POINT HEAD (1/2-13X3-IN) | 4 | |
| 0S0175 | 22 PIN-CLEVIS | 2 | |
| 1S8687 | 23 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 2S6151 | 24 GASKET | 1 | |
| 2S6160 | 25 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 3L1425 | 26 BALL BEARING | 1 | |
| 4M6425 | 27 BOLT (5/16-18X1-IN) | 4 | |
| 5M3062 | 28 BOLT (3/8-16X0.75-IN) | 1 | |
| 5M6214 | 29 PLUG (1/8-27 PTF) | 1 | |
| 5S2106 | 30 SEAL-LIP TYPE | 1 | |
| 5S7379 | 31 BOLT (3/8-16X0.875-IN) | 1 | |
| 5S9062 | 32 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 6B1124 | 33 BALL BEARING | 2 | |
| 6H3956 | 34 PIN | 1 | |
| 6V8188 | 35 NUT (1/2-13-THD) | 1 | |
| 6V8801 | 36 NUT (3/8-16-THD) | 6 | |
| 7X2550 | 37 BOLT (M12X1.75X110-MM) | 2 | |
| 8H9789 | 38 BALL BEARING | 1 | |
| 8T4121 | 39 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4185 | 40 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4223 | 41 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4896 | 42 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 8T6868 | 43 BOLT (M12X1.75X80-MM) | 2 | |
| 8T7008 | 44 BOLT (3/8-16X3-IN) | 6 | |
| 8T8920 | 45 BOLT (1/2-13X3.25-IN) | 4 | |
| 9F4446 | 46 SEAL-O-RING | 1 |
