Assembly
100%

225-4222 RADIATOR GPS/N EED1318-UP

Group No: 225-4222 · Commonality
Part NumberPart NameQty
8D37861 MOUNTING8
25135882 RADIATOR GP1
29152033 BOLT-HEAD (M10X1.5X40-MM)(M10X1.5X40-MM)4
32724684 BRACKET AS2
36307325 BRACKET AS2
17268336 CLIP (LOOP)2
19847777 WASHER-HARD (11X25X10-MM THK)4
19847808 WASHER-HARD (17.5X32X8-MM THK)4
3S86649 CLIP2
5P107610 WASHER-HARD (13.5X30X4-MM THK)8
7X059011 WASHER-HARD (13.5X44.5X6-MM THK)16
8T412112 WASHER-HARD (11X21X2.5-MM THK)2
8T413313 NUT (M10X1.5-THD)1
8T413614 BOLT (M10X1.5X25-MM)1
8T419315 BOLT (M16X2X50-MM)4
8T422316 WASHER-HARD (13.5X25.5X3-MM THK)8
8T424417 NUT (M12X1.75-THD)8
8T464818 BOLT (M12X1.75X70-MM)8
8T891719 BOLT (1/2-13X1.25-IN)8
423198120 HOSE (81-IN)
