System And Components
293-8632 WIRING GP-LIGHTINGS/N EED1194-UP
Group No: 293-8632 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2196487 | 1 LAMP GP-FLOOD (24-VOLT, 70-WATT) | 4 | |
| 3217434 | 2 HARNESS AS-LIGHTING (LH) | 1 | |
| 3217435 | 3 HARNESS AS-LIGHTING (RH) | 1 | |
| 1863736 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 1148843 | SLEEVE-PLASTIC (60-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 3 | |
| 3209649 | 4 PLATE | 1 | |
| 3326571 | 5 PLATE AS | 1 | |
| 3339222 | 6 HARNESS AS-WIRING (MIRROR) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1863736 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1148843 | SLEEVE-PLASTIC (40-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1305300 | 7 CLIP | 1 | |
| 5P1075 | 8 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 7G7053 | 9 GROMMET | 2 | |
| 7K1181 | 10 STRAP-CABLE | 8 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4137 | 12 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4195 | 13 BOLT (M10X1.5X30-MM) | 2 | |
| 3385116 | 14 HARNESS AS-WIRING (HEATED MIRROR) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 |
