System And Components
247-5622 WIRING GP-PLATFORM -LHS/N EED372-601
Group No: 247-5622 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 9 | |
| 9F8125 | 2 LOCKWASHER | 3 | |
| 1350427 | 3 LAMP GP-SIGNAL (24-VOLT, PARK, TURN) | 1 | |
| 1392116 | 4 SWITCH GP-TOGGLE (LADDER LIGHTS) | 1 | |
| 1392116 | 4A SWITCH GP-TOGGLE (GROUND LEVEL SHUTDOWN) | 1 | |
| 2350100 | 5 HARNESS AS-PLATFORM (LH) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 9X0145 | RECEPTACLE AS-CONNECTOR (24-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 3 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 2418488 | 6 PLATE | 1 | |
| 2469871 | 7 LAMP GP-MARKER (24-VOLT, AMBER) | 1 | |
| 0309612 | 8 SCREW-FORMING (10-24X0.5-IN) | 3 | |
| 1179409 | 9 GROMMET | 1 | |
| 1305300 | 10 CLIP | 7 | |
| 3E5169 | 11 GUARD-SWITCH | 1 | |
| 4P7581 | 12 CLIP (LADDER) | 2 | |
| 5C2890 | 13 NUT (M6X1-THD) | 3 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4137 | 15 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4205 | 16 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 5P0767 | 18 HOSE (83-CM) | ||
| 5P0767 | 18A HOSE (90-CM) | ||
| 7K1181 | 19 STRAP-CABLE | 10 |
