System And Components
274-7947 GUARD GP-BELTS/N DLS1-UP
Group No: 274-7947 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3343833 | 1 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3343834 | 2 BRACKET AS | 1 | |
| 3424447 | 3 INSERT | 4 | |
| 3491199 | 4 BRACKET AS | 1 | |
| 3491200 | 5 PLATE AS | 1 | |
| 3505697 | 6 GUARD AS-BELT | 1 | |
| 7X0579 | WASHER-HARD (8.8X25.5X2-MM THK) | 7 | |
| 8T4908 | BOLT (M8X1.25X25-MM) | 7 | |
| 1165763 | CLIP-SPRING | 7 | |
| 1984776 | 7 WASHER-HARD (8.8X20X8-MM THK) | 4 | |
| 3055385 | 8 BOLT (M8X1.25X50-MM) | 4 | |
| 5P4116 | 9 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 8T4189 | 10 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4956 | 11 BOLT (M12X1.75X35-MM) | 2 | |
| 8T7971 | 12 WASHER-HARD (13.5X25.5X5-MM THK) | 2 |
