System And Components
302-4288 HOUSING GP-FLYWHEELS/N LJX113-UP
Group No: 302-4288 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7G9724 | 1 SPACER (10.5X18X19-MM THK) | 4 | |
| 3190785 | 2 SEAL GP-CRANKSHAFT (REAR) | 1 | |
| 2251242 | 3 GASKET | 1 | |
| 3024289 | 4 HOUSING AS-FLYWHEEL | 1 | |
| 2389860 | DOWEL | 2 | |
| 1W3136 | BAFFLE | 1 | |
| 0S1619 | 5 BOLT (3/8-16X3-IN) | 2 | |
| 1700612 | 6 STUD (3/8-16X4-IN) | 4 | |
| 2314470 | 7 BOLT (3/8-16X6.25-IN) | 2 | |
| 2314471 | 8 BOLT (1/2-13X6.5-IN) | 8 | |
| 5B2638 | 9 BOLT (3/8-16X5.25-IN) | 14 | |
| 5M2894 | 10 WASHER-HARD (10.2X18.5X2.5-MM THK) | 28 | |
| 5P7814 | 11 SEAL-O-RING | 1 | |
| 5P8245 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8S9191 | 13 BOLT (3/8-16X4-IN) | 6 | |
| 9S8003 | 14 PLUG (1/2-20-THD) | 1 |
