System And Components
213-4836 PISTON & ROD GPS/N LJX1265-UP
Group No: 213-4836 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1501156 | 1 BOLT-SPECIAL (OIL JET) | 1 | |
| 1644187 | 2 RING-PISTON (INTERMEDIATE) | 1 | |
| 5245565 | 3 PIN-PISTON | 1 | |
| 2502940 | 4 RETAINER-PIN | 2 | |
| 2323226 | 5 BEARING-CONNECTING ROD (STANDARD) | 1 | |
| 3410060 | BEARING-CONNECTING ROD (0.63-MM US) | ||
| 2323232 | 6 ROD AS | 1 | |
| 2133217 | 6A BOLT (M11X1.25X84-MM) | 4 | |
| 2194458 | 6B PIN-DOWEL | 2 | |
| 2296259 | 6C BEARING | 1 | |
| 3577163 | 7 TUBE AS-OIL JET | 1 | |
| 3767362 | 8 BODY AS-PISTON | 1 | |
| 2476130 | 9 RING-PISTON-TOP | 1 | |
| 2380294 | 10 RING-PISTON (OIL) | 1 |
