System And Components
260-1714 SUPPORT GP-ENGINES/N DLS1-UP
Group No: 260-1714 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X0368 | 1 BOLT (3/4-10X3-IN) | 4 | |
| 6N3896 | 2 CAP | 2 | |
| 6Y9960 | 3 MOUNT AS | 2 | |
| 9W8095 | PAD-REBOUND | 1 | |
| 8W6731 | 4 WASHER (27X100X12-MM THK) | 2 | |
| 9W7385 | 5 SLEEVE | 2 | |
| 9W7388 | 6 WASHER (26X144X12-MM THK) | 2 | |
| 2697585 | 7 SUPPORT AS | 1 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 5M3012 | LUG (3/8-16-THD) | 3 | |
| 8X6102 | BLOCK | 1 | |
| 7X0375 | 8 BOLT (3/4-10X5-IN) | 4 | |
| 7X0417 | 9 BOLT (1-8X9-IN) | 2 | |
| 6V8182 | 10 NUT (3/4-10-THD) | 8 | |
| 6V8190 | 11 NUT (1-8-THD) | 2 | |
| 8T4994 | 12 WASHER-HARD (20X36.5X3.5-MM THK) | 16 | |
| 8T5361 | 13 WASHER-HARD (28X49X5-MM THK) | 4 | |
| 2758372 | 14 WASHER (26X144X18.5-MM THK) | 2 |
