System And Components
225-4226 FAN GP-SUCTIONS/N DLS1-UP
Group No: 225-4226 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2397856 | 1 SPIDER AS-FAN (8-BLADE) | 1 | |
| 2534548 | 2 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 2563616 | 3 GUARD AS-FAN | 1 | |
| 2563617 | 4 GUARD AS-FAN | 1 | |
| 2563618 | 5 GUARD AS-FAN | 1 | |
| 2563624 | 6 SHROUD AS-FAN | 1 | |
| 2563630 | 7 BRACKET AS | 1 | |
| 7X7729 | 8 WASHER (11X25X3-MM THK) | 32 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4136 | 10 BOLT (M10X1.5X25-MM) | 9 | |
| 8T4195 | 11 BOLT (M10X1.5X30-MM) | 23 | |
| 8T4196 | 12 BOLT (M10X1.5X35-MM) | 9 |
