230-7697 LINES GP-WATERS/N LJX1-UP

Group No: 230-7697 · Commonality

Part Number	Part Name	Qty
3438888	1 GASKET	1
4N2198	2 FLANGE	1
4N2199	3 GASKET	2
4N2380	4 SPACER-SPECIAL (OIL COOLER)	1
4N8452	5 SUPPORT	1
4W1118	6 PLATE	1
4W1120	7 BRACKET AS	1
6N0008	8 ADAPTER	1
7C0145	9 CORE AS-OIL COOLER (ENGINE)(ENGINE OIL)	1
7S8767	10 GASKET	4
1041817	11 CORE AS-OIL COOLER (TRANSMISSION)	1
8T6764	PLUG-PIPE (1/8-27-THD)	2
1248909	12 ELBOW	1
1414109	13 CORE GP-OIL COOLER (BRAKE)	1
1570670	14 CAP-DUST	1
1765647	15 PLATE	1
2246079	16 SEAL-O-RING	1
2354753	17 ELBOW	1
2374180	18 COVER-WATER PUMP	1
2380281	19 BONNET (ENGINE OIL COOLER)	1
2380995	20 BONNET	1
2380996	21 BONNET	1
0L1143	22 BOLT (3/8-16X2.5-IN)	1
0L1351	23 BOLT (3/8-16X0.875-IN)	4
0S1588	24 BOLT (3/8-16X1.25-IN)	5
0S1591	25 BOLT (3/8-16X1.5-IN)	2
0S1594	26 BOLT (3/8-16X1-IN)	4
0S1619	27 BOLT (3/8-16X3-IN)	7
0V0375	28 BOLT (1/2-13X3.25-IN)	11
1090074	29 SEAL-O-RING	1
1090075	30 SEAL-O-RING	1
1090077	31 SEAL-O-RING	2
1549023	32 VALVE-SAMPLING (ENGINE COOLANT)	1
1A2029	33 BOLT (3/8-16X1.125-IN)	6
1D4569	34 BOLT (1/2-13X4.25-IN)	2
3B1915	35 BOLT (3/8-16X1.375-IN)	5
5M2894	36 WASHER-HARD (10.2X18.5X2.5-MM THK)	12
7D1649	37 WASHER-HARD (13.5X32X5-MM THK)	2
5P4499	38 ADAPTER	1
5P8245	39 WASHER-HARD (13.5X25.5X3-MM THK)	1
9S8008	40 PLUG (1-1/16-12-THD)	5
6V5063	41 SEAL-O-RING	6
6V5064	42 SEAL-O-RING	1
6V9027	43 SEAL-O-RING	6
7C0307	44 GASKET	1
9S9334	45 PLUG (1-5/16-12-THD)	1
4N1946	46 GASKET	1
9S8002	47 PLUG (7/16-20-THD)	4
9X8873	48 BOLT (1/2-13X2.25-IN)	6
9X8874	49 BOLT (1/2-13X3-IN)	5
9X8877	50 BOLT (1/2-13X5-IN)	1
9K7290	51 BOLT-12 POINT HEAD (1/2-13X3.25-IN)	1
