System And Components
225-4222 RADIATOR GPS/N DLS1-447
Group No: 225-4222 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2513588 | 1 RADIATOR GP | 1 | |
| 2514571 | 2 PLATE AS | 2 | |
| 2529160 | 3 BRACKET AS | 2 | |
| 2891560 | 4 BRACKET AS | 2 | |
| 3S8664 | 5 CLIP | 2 | |
| 4Y3046 | 6 WASHER (13.5X38X3-MM THK) | 8 | |
| 8T4140 | 7 BOLT (M16X2X60-MM) | 4 | |
| 8D3786 | 8 MOUNTING | 8 | |
| 7X7729 | 9 WASHER (11X25X3-MM THK) | 16 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 8 | |
| 8T6466 | 11 BOLT (M10X1.5X60-MM) | 8 | |
| 2915203 | 12 BOLT-HEAD (M10X1.5X40-MM)(M10X1.5X40-MM) | 4 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T8917 | 14 BOLT (1/2-13X1.25-IN) | 16 | |
| 5P7197 | 15 WASHER (17X45X6-MM THK) | 12 | |
| 5P1420 | 16 HOSE (196-CM) | ||
| 1984777 | 17 WASHER-HARD (11X25X10-MM THK) | 4 |
