System And Components
225-4222 RADIATOR GPS/N DLS448-1361
Group No: 225-4222 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2513588 | 1 RADIATOR GP | 1 | |
| 2514571 | 2 PLATE AS | 2 | |
| 3272469 | 3 BRACKET AS | 2 | |
| 3272468 | 4 BRACKET AS | 2 | |
| 1984777 | 5 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 7X0590 | 6 WASHER-HARD (13.5X44.5X6-MM THK) | 16 | |
| 8T4193 | 7 BOLT (M16X2X50-MM) | 4 | |
| 8D3786 | 8 MOUNTING | 8 | |
| 5P1076 | 9 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 8T4244 | 10 NUT (M12X1.75-THD) | 8 | |
| 8T4648 | 11 BOLT (M12X1.75X70-MM) | 8 | |
| 2915203 | 12 BOLT-HEAD (M10X1.5X40-MM)(M10X1.5X40-MM) | 4 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T8917 | 14 BOLT (1/2-13X1.25-IN) | 16 | |
| 1984780 | 15 WASHER-HARD (17.5X32X8-MM THK) | 4 | |
| 5P1420 | 16 HOSE (196-CM) |
