System And Components
227-9992 AIR CLEANER GPS/N DLS1-544
Group No: 227-9992 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7S1131 | 1 HOSE-ADAPTER | 1 | |
| 8N5991 | 2 HOSE | 2 | |
| 9N0720 | 3 ELBOW-AIR INLET | 2 | |
| 1230275 | 4 CONNECTOR-FILTER | 2 | |
| 1505030 | 5 INDICATOR-AIR FILTER CHANGE | 2 | |
| 2051627 | 6 BRACKET | 2 | |
| 2162212 | 7 CLAMP | 10 | |
| 2338484 | 8 CLAMP (BOLT SPRING) | 4 | |
| 2405159 | 9 BRACKET AS | 1 | |
| 2543566 | 10 AIR CLEANER GP | 2 | |
| 2544293 | 11 CAP GP-AIR CLEANER | 2 | |
| 5P0600 | CLAMP-HOSE | 1 | |
| 2545719 | 12 MANIFOLD AS | 1 | |
| 2545723 | 13 BRACKET | 1 | |
| 2545724 | 14 BRACKET | 1 | |
| 2545727 | 15 TUBE | 1 | |
| 2545728 | 16 TUBE AS | 1 | |
| 2550099 | 17 BRACKET AS | 1 | |
| 2562420 | 18 ELBOW | 2 | |
| 2690207 | 19 BRACKET AS | 1 | |
| 1658718 | NUT-WELD (M4X0.7-THD) | 4 | |
| 2808533 | 20 TUBE | 1 | |
| 0966166 | 21 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 3B6487 | 22 COUPLING (PIPE) | 2 | |
| 4D8123 | 23 CLIP (LOOP) | 4 | |
| 8T0285 | 24 SCREW-MACHINE (M4X0.7X12-MM) | 4 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 26 | |
| 8T4136 | 26 BOLT (M10X1.5X25-MM) | 24 | |
| 8T4139 | 27 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4195 | 28 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 6V1363 | 30 HOSE (1.025-M EACH) |
