Assembly
100%

251-1573 EXHAUST AR-BODYS/N DLS1-459

Group No: 251-1573 · Commonality
Part NumberPart NameQty
2P78061 CLAMP2
25786162 TUBE1
26398573 PIPE GP-EXHAUST1
26402524 PIPE AS-EXHAUST1
27638555 PLATE2
28122606 TUBE AS1
28122617 PIPE GP-EXHAUST1
28122728 MUFFLER GP1
29281489 SHIELD-HEAT1
4N933010 CLAMP2
7X256311 BOLT (M20X2.5X60-MM)6
6V583912 WASHER (11X21X2.5-MM THK)4
8T543913 WASHER-HARD (21.5X45X6-MM THK)6
2Y582914 NUT (M10X1.5-THD)2
8T413915 BOLT (M12X1.75X30-MM)2
6V819716 BOLT (M12X1.75X40-MM)12
6V424917 BOLT (M10X1.5X50-MM)2
6V382318 BOLT (M12X1.75X60-MM)2
8T422319 WASHER-HARD (13.5X25.5X3-MM THK)2
6V814920 NUT (M12X1.75-THD)2
7D164921 WASHER-HARD (13.5X32X5-MM THK)4
5P824522 WASHER-HARD (13.5X25.5X3-MM THK)12
