System And Components
251-1573 EXHAUST AR-BODYS/N DLS460-1027
Group No: 251-1573 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1411480 | 1 CLAMP AS | 2 | |
| 2578616 | 2 TUBE | 1 | |
| 2639857 | 3 PIPE GP-EXHAUST | 1 | |
| 2640252 | 4 PIPE AS-EXHAUST | 1 | |
| 2763855 | 5 PLATE | 2 | |
| 2812260 | 6 TUBE AS | 1 | |
| 2812261 | 7 PIPE GP-EXHAUST | 1 | |
| 2928148 | 8 SHIELD-HEAT | 1 | |
| 3129107 | 9 MUFFLER GP | 1 | |
| 4N9330 | 10 CLAMP | 2 | |
| 5P8245 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 6V3823 | 12 BOLT (M12X1.75X60-MM) | 2 | |
| 6V8149 | 13 NUT (M12X1.75-THD) | 2 | |
| 6V8197 | 14 BOLT (M12X1.75X40-MM) | 12 | |
| 7D1649 | 15 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 7X2563 | 16 BOLT (M20X2.5X60-MM) | 6 | |
| 8T4139 | 17 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T5439 | 19 WASHER-HARD (21.5X45X6-MM THK) | 6 |
