System And Components
252-4425 EXHAUST AR-ENGINES/N DLS1-1027
Group No: 252-4425 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1411480 | 1 CLAMP AS | 2 | |
| 2578616 | 2 TUBE | 1 | |
| 2578617 | 3 MUFFLER GP | 1 | |
| 2640252 | 4 PIPE AS-EXHAUST | 1 | |
| 2763855 | 5 PLATE | 2 | |
| 2812260 | 6 TUBE AS | 1 | |
| 2812261 | 7 PIPE GP-EXHAUST | 1 | |
| 2928148 | 8 SHIELD-HEAT | 1 | |
| 3113044 | 9 PLATE | 1 | |
| 0S1595 | 10 BOLT (1/2-13X1.25-IN) | 4 | |
| 0S1621 | 11 BOLT (1/2-13X1-IN) | 4 | |
| 4N9330 | 12 CLAMP | 2 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 6V3823 | 14 BOLT (M12X1.75X60-MM) | 2 | |
| 6V8149 | 15 NUT (M12X1.75-THD) | 2 | |
| 6V8197 | 16 BOLT (M12X1.75X40-MM) | 8 | |
| 7D1649 | 17 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 7X2563 | 18 BOLT (M20X2.5X60-MM) | 6 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T5439 | 21 WASHER-HARD (21.5X45X6-MM THK) | 6 |
