System And Components
252-4427 EXHAUST AR-ENGINES/N DLS1028-UP
Group No: 252-4427 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1411480 | 1 CLAMP AS | 2 | |
| 2566911 | 2 PLATE AS-EXHAUST | 1 | |
| 2578616 | 3 TUBE | 1 | |
| 2578617 | 4 MUFFLER GP | 1 | |
| 2639857 | 5 PIPE GP-EXHAUST | 1 | |
| 3367282 | 6 PIPE GP-EXHAUST | 1 | |
| 8X4726 | PLATE | 1 | |
| 2812260 | 7 TUBE AS | 1 | |
| 2812261 | 8 PIPE GP-EXHAUST | 1 | |
| 4N9330 | 9 CLAMP | 2 | |
| 7X2563 | 10 BOLT (M20X2.5X60-MM) | 6 | |
| 3E4353 | 11 WASHER-HARD (11X25X3-MM THK) | 4 | |
| 8T5439 | 13 WASHER-HARD (21.5X45X6-MM THK) | 6 | |
| 8T4139 | 15 BOLT (M12X1.75X30-MM) | 2 | |
| 6V8197 | 16 BOLT (M12X1.75X40-MM) | 4 | |
| 6V3823 | 18 BOLT (M12X1.75X60-MM) | 2 | |
| 6V1820 | 19 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V7687 | 21 LOCKNUT (M12X1.75-THD) | 2 | |
| 3596250 | 22 SHIELD-HEAT | 1 | |
| 7D1649 | 23 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 5P8245 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 4 |
