System And Components
227-9998 LINES GP-AIRS/N DLS1-447
Group No: 227-9998 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7S8780 | 1 HOSE | 4 | |
| 1270929 | 2 CLAMP-V BAND | 2 | |
| 2171601 | 3 HOSE-ELBOW | 2 | |
| 2178946 | 4 ELBOW | 2 | |
| 2529652 | 5 TUBE | 1 | |
| 2529653 | 6 TUBE | 1 | |
| 2529654 | 7 TUBE | 1 | |
| 2529655 | 8 TUBE | 1 | |
| 2529656 | 9 TUBE | 1 | |
| 2529657 | 10 TUBE | 1 | |
| 2540736 | 11 BRACKET AS | 1 | |
| 2540737 | 12 BRACKET AS | 1 | |
| 2544129 | 13 TUBE | 1 | |
| 2544130 | 14 TUBE | 1 | |
| 4L9337 | 15 BOLT (3/8-16X1.5-IN) | 2 | |
| 1565745 | 16 CLAMP-HALF | 4 | |
| 2087448 | 17 CLAMP | 20 | |
| 2094590 | 18 CLAMP-T BOLT | 4 | |
| 5C6565 | 19 BOLT (1/2-13X1.125-IN) | 2 | |
| 6V5048 | 20 SEAL-O-RING | 2 | |
| 6V6782 | 21 CLIP (SLOT) | 5 | |
| 6V6783 | 22 CLIP (TAB) | 5 | |
| 7E8630 | 23 HOSE-AIR INLET | 6 | |
| 7X7729 | 24 WASHER (11X25X3-MM THK) | 6 | |
| 8C3089 | 25 SEAL-O-RING | 2 | |
| 8T4133 | 26 NUT (M10X1.5-THD) | 1 | |
| 8T4139 | 27 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4186 | 28 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4195 | 29 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 9S8002 | 31 PLUG (7/16-20-THD) | 2 | |
| 5P1075 | 32 WASHER-HARD (10.2X22.5X3-MM THK) | 2 |
