System And Components
307-3550 LAMP GP-PAYLOAD SIGNAL -TRUCK PAYLOAD MEASUREMENT SYSTEMS/N DLS604-UP
Group No: 307-3550 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 9 | |
| 9F8125 | 2 LOCKWASHER | 12 | |
| 1695414 | 3 CLIP | 2 | |
| 2481264 | 4 PLATE AS | 2 | |
| 8F9836 | BOSS (3/8-16-THD) | 1 | |
| 2481265 | 5 BRACKET AS | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 3069391 | 6 HARNESS AS-WIRING (PAYLOAD SIGNAL LAMP)(LH) | 1 | |
| 3069392 | 7 HARNESS AS-WIRING (PAYLOAD SIGNAL LAMP)(RH) | 1 | |
| 3073541 | 8 PLATE AS | 1 | |
| 3073545 | 9 PLATE AS | 1 | |
| 1179409 | 10 GROMMET | 1 | |
| 2469869 | 11 LAMP GP-PAYLOAD SIGNAL (24-VOLT)(RED) | 2 | |
| 2469870 | 12 LAMP GP-PAYLOAD SIGNAL (24-VOLT)(GREEN) | 2 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 5M3062 | 13 BOLT (3/8-16X0.75-IN) | 10 | |
| 6V2687 | 14 SCREW-PAN HEAD (10-24X1-IN) | 12 | |
| 8K1433 | 15 GROMMET | 2 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 15 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 11 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 1H7459 | 20 GROMMET | 1 | |
| 3172076 | 21 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 |
