System And Components
247-5642 LIGHTING GP-FLOOD -REAR, RHS/N DLS1-UP
Group No: 247-5642 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 5 | |
| 1306469 | 2 BRACKET AS | 1 | |
| 2475638 | 3 BRACKET AS | 1 | |
| 2475643 | 4 HARNESS AS-REAR | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1305300 | 5 CLIP | 3 | |
| 1712065 | 6 LAMP GP-FLOOD (24-VOLT)(BACKUP) | 1 | |
| 2326136 | 7 LAMP GP-SIGNAL (24-VOLT)(STOP, TURN, TAIL, RH) | 1 | |
| 3E3377 | WEDGE-RECEPTACLE LOCK (4-PIN) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 2 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 5C7261 | 8 NUT (M8X1.25-THD) | 1 | |
| 6V8225 | 9 NUT (M6X1-THD) | 3 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 11 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4191 | 12 BOLT (M10X1.5X16-MM) | 3 | |
| 8T4205 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6869 | 15 BOLT (M8X1.25X60-MM) | 1 |
