System And Components
264-5780 SENSOR & MTG GP-PAYLOADS/N DLS1-UP
Group No: 264-5780 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4L7124 | 1 BOLT (1/4-20X1.25-IN) | 8 | |
| 1291029 | 2 VALVE GP-CHECK (PAYLOAD MONITOR) | 4 | |
| 1753185 | CORE-VALVE | 1 | |
| 2213417 | 3 SENSOR GP-PRESSURE (VARIABLE FREQUENCY)(PAYLOAD MONITOR) | 4 | |
| 2284929 | 4 BLOCK AS | 4 | |
| 4402667 | 5 VALVE AS (SUSPENSION CYLINDER CHARGING) | 4 | |
| 2424313 | SEAL-O-RING | 1 | |
| 4402668 | CORE-VALVE | 1 | |
| 2431768 | 6 BLOCK | 4 | |
| 0300167 | 7 RING-BACKUP | 4 | |
| 0336039 | 8 SEAL-O-RING | 4 | |
| 1143361 | 9 SEAL-O-RING | 4 | |
| 3J1907 | 10 SEAL-O-RING | 4 | |
| 5P0537 | 11 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 5S7383 | 12 BOLT (3/8-16X1.75-IN) | 8 | |
| 8M4435 | 13 SEAL-O-RING | 4 | |
| 8T4896 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4137 | 16 BOLT (M10X1.5X20-MM) | 1 | |
| 4P7581 | 17 CLIP (LADDER) | 1 |
