System And Components
245-2774 SENSOR GP-SPEEDS/N NJE1-UP
Group No: 245-2774 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B3867 | 1 BALL BEARING | 1 | |
| 6T5611 | 2 SPACER (9.75X17.5X16.25-MM THK) | 5 | |
| 6T5612 | 3 GROMMET | 5 | |
| 6T5613 | 4 SPACER (7.85-MM THK) | 1 | |
| 1171385 | 5 SEAL-O-RING | 2 | |
| 1481507 | 6 ROTOR-SENSOR | 1 | |
| 2016615 | 7 SENSOR GP-SPEED (TRANSMISSION) | 2 | |
| 2032060 | 8 RETAINER-BEARING | 1 | |
| 4757424 | 9 GUARD AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 2580953 | 10 HOUSING | 1 | |
| 0L1351 | 11 BOLT (3/8-16X0.875-IN) | 4 | |
| 1305300 | 12 CLIP | 2 | |
| 2A4639 | 13 BOLT (3/8-16X1.625-IN) | 2 | |
| 2H3755 | 14 BOLT (5/16-18X0.43-IN) | 2 | |
| 2S6160 | 15 WASHER-HARD (10.2X32X5-MM THK) | 5 | |
| 3B1915 | 16 BOLT (3/8-16X1.375-IN) | 3 | |
| 4P8134 | 17 CLIP (LADDER) | 3 | |
| 5M2894 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P0537 | 19 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 7K1181 | 20 STRAP-CABLE | 2 | |
| 8H3128 | 21 BOLT-SOCKET HEAD (1/4-20X0.625-IN) | 4 | |
| 8H3981 | 22 RING-RETAINING | 1 |
