235-0107 WIRING GP-ENGINES/N DLS1-374

Group No: 235-0107 · Commonality
Part NumberPart NameQty
3S20931 STRAP-CABLE3
7T02662 BRACKET AS1
1F0750NUT-WELD (3/8-16-THD)1
8P96793 SPACER (10.5X25X40-MM THK)1
11083304 SPACER (11.3X19.05X90-MM THK)3
11453335 SWITCH AS-PRESSURE (AIR CONDITIONER)1
1028802KIT-RECEPTACLE (2-PIN)2
1863735PIN-CONNECTOR (16-GA TO 18-GA)2
9X1386SLEEVE (25-CM)
13422526 SENSOR GP-TEMPERATURE (8-VOLT)(ENGINE OIL)1
14963717 SWITCH AS-PRESSURE (A/C COMPRESSOR CLUTCH)(REFRIGERANT COMPR, LOW SIDE)1
1028802KIT-RECEPTACLE (2-PIN)2
1863735PIN-CONNECTOR (16-GA TO 18-GA)2
31811818 SENSOR GP-SPEED (MAGNETIC)(ENGINE)1
23501089 HARNESS AS-ENGINE1
9X6772STRAP-CABLE2
1261774COVER-CONNECTOR1
1028805KIT-RECEPTACLE (6-PIN)1
9X1343RECEPTACLE AS-CONNECTOR (40-PIN)1
1886210RECEPTACLE AS-CONNECTOR (1-PIN)1
1552260KIT-CONNECTING PLUG (3-PIN)1
1552271KIT-CONNECTING PLUG (4-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)5
1552274KIT-CONNECTING PLUG (6-PIN)1
1552272PLUG AS-CONNECTOR (4-PIN)1
1607689PLUG AS-CONNECTOR (70-PIN)1
9X6772STRAP-CABLE2
241848810 PLATE1
248795911 STUD-TERMINAL1
266374912 PLATE AS1
130530013 CLIP4
169744314 TIMER AS-ON DELAY (24-VOLT)1
1028804KIT-RECEPTACLE (4-PIN)1
1863735PIN-CONNECTOR (16-GA TO 18-GA)4
3J190715 SEAL-O-RING1
4P742816 CLIP (LADDER)1
4P742917 CLIP (LADDER)1
4P758118 CLIP (LADDER)11
4P813419 CLIP (LADDER)13
5C287420 NUT (M5X0.8-THD)2
5C955321 BOLT (M6X1X16-MM)2
5M306222 BOLT (3/8-16X0.75-IN)1
5N791723 SPACER (10.74X17.14X54.4-MM THK)2
6V880124 NUT (3/8-16-THD)2
7K118125 STRAP-CABLE26
8C858026 BOLT-SOCKET HEAD (M5X0.8X16-MM)2
8T412127 WASHER-HARD (11X21X2.5-MM THK)6
8T413628 BOLT (M10X1.5X25-MM)1
8T413729 BOLT (M10X1.5X20-MM)2
8T419530 BOLT (M10X1.5X30-MM)3
8T489631 WASHER-HARD (10.2X18.5X2.5-MM THK)9
8T910132 BOLT (3/8-16X2.75-IN)3
8T937933 BOLT (3/8-16X4.25-IN)3
9X737834 SEAL-O-RING1
8F359035 LOCKWASHER1
