Assembly
100%

286-9972 WIRING GP-LIGHTING -HID, FRONTS/N DLS1-603

Group No: 286-9972 · Commonality
Part NumberPart NameQty
2G87671 WASHER (10.5X60X3-MM THK)2
3S20932 STRAP-CABLE18
9L30593 SUPPORT-TUBE2
12703664 SPACER (11X32X24-MM THK)2
16312015 HORN AS (24-VOLT, LOW TONE)1
17478756 HORN AS (24-VOLT, HIGH TONE)1
24756337 HARNESS AS-LIGHTING2
1028802KIT-RECEPTACLE (2-PIN)1
1028805KIT-RECEPTACLE (6-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)4
28383978 HARNESS AS-LIGHTING2
1552270KIT-CONNECTING PLUG (2-PIN)2
13053009 CLIP2
164759510 LAMP GP-HEAD (24-VOLT)(LOW BEAM)2
164759911 LAMP GP-HEAD (24-VOLT)(HIGH BEAM)2
210842312 LAMP GP-FLOOD (24-VOLT, 35-WATT, HID)2
4P758113 CLIP (LADDER)10
4P813414 CLIP (LADDER)4
8P854015 GROMMET2
8T412116 WASHER-HARD (11X21X2.5-MM THK)19
8T413317 NUT (M10X1.5-THD)6
8T413718 BOLT (M10X1.5X20-MM)13
8T419619 BOLT (M10X1.5X35-MM)2
8T947120 GROMMET2
