Assembly
100%

286-9972 WIRING GP-LIGHTING -HID, FRONTS/N DLS604-UP

Group No: 286-9972 · Commonality
Part NumberPart NameQty
3S20931 STRAP-CABLE10
12703662 SPACER (11X32X24-MM THK)2
16312013 HORN AS (24-VOLT, LOW TONE)1
17478754 HORN AS (24-VOLT, HIGH TONE)1
21964865 LAMP GP-FLOOD (24-VOLT)2
21964876 LAMP GP-FLOOD (24-VOLT, 70-WATT)2
25524967 BRACKET4
13053008 CLIP2
16475959 LAMP GP-HEAD (24-VOLT)(LOW BEAM)2
210842310 LAMP GP-FLOOD (24-VOLT, 35-WATT, HID)2
302450111 HARNESS AS-FRONT LIGHTING2
5P107612 WASHER-HARD (13.5X30X4-MM THK)4
6V814913 NUT (M12X1.75-THD)2
8P854014 GROMMET2
8T412115 WASHER-HARD (11X21X2.5-MM THK)8
8T413316 NUT (M10X1.5-THD)2
8T413717 BOLT (M10X1.5X20-MM)4
8T418318 BOLT (M12X1.75X40-MM)2
8T947119 GROMMET1
