System And Components
247-5622 WIRING GP-PLATFORM -LHS/N DLS604-904
Group No: 247-5622 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 3 | |
| 9F8125 | 2 LOCKWASHER | 3 | |
| 1350427 | 3 LAMP GP-SIGNAL (24-VOLT, PARK, TURN) | 1 | |
| 1392116 | 4 SWITCH GP-TOGGLE (LADDER LIGHTS) | 1 | |
| 1392116 | 4A SWITCH GP-TOGGLE (GROUND LEVEL SHUTDOWN) | 1 | |
| 1695414 | 5 CLIP | 2 | |
| 2418488 | 6 PLATE | 1 | |
| 2469871 | 7 LAMP GP-MARKER (24-VOLT, AMBER) | 1 | |
| 3024502 | 8 HARNESS AS-PLATFORM | 1 | |
| 3131330 | 9 PLATE AS | 1 | |
| 0309612 | 10 SCREW-FORMING (10-24X0.5-IN) | 3 | |
| 1305300 | 11 CLIP | 3 | |
| 4D3100 | 12 GROMMET | 1 | |
| 3E5169 | 13 GUARD-SWITCH | 1 | |
| 4P7581 | 14 CLIP (LADDER) | 1 | |
| 4P8134 | 15 CLIP (LADDER) | 4 | |
| 5C2890 | 16 NUT (M6X1-THD) | 3 | |
| 6K8180 | 17 GROMMET | 1 | |
| 7K1181 | 18 STRAP-CABLE | 15 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4136 | 20 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 21 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4205 | 22 WASHER-HARD (7.2X14.5X2-MM THK) | 3 |
