System And Components
247-5623 WIRING GP-PLATFORM -RHS/N DLS604-1186
Group No: 247-5623 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 21 | |
| 9F8125 | 2 LOCKWASHER | 9 | |
| 3024504 | 3 HARNESS AS-PLATFORM | 1 | |
| 3035906 | 4 HARNESS AS-PLATFORM (LIGHTS, MIRRORS) | 1 | |
| 0309612 | 5 SCREW-FORMING (10-24X0.5-IN) | 9 | |
| 1305300 | 6 CLIP | 5 | |
| 1350427 | 7 LAMP GP-SIGNAL (24-VOLT, PARK, TURN) | 1 | |
| 2469871 | 8 LAMP GP-MARKER (24-VOLT, AMBER)(SIDE MARKER, RH) | 1 | |
| 2469871 | 8A LAMP GP-MARKER (24-VOLT, AMBER)(MACHINE LOCKOUT) | 1 | |
| 2469871 | 8B LAMP GP-MARKER (24-VOLT, AMBER)(ENGINE LOCKOUT) | 1 | |
| 4H2558 | 9 GROMMET | 1 | |
| 4P7581 | 10 CLIP (LADDER) | 3 | |
| 5C2890 | 11 NUT (M6X1-THD) | 3 | |
| 7K1181 | 12 STRAP-CABLE | 2 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 15 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4205 | 16 WASHER-HARD (7.2X14.5X2-MM THK) | 3 |
