System And Components
249-7065 WIRING GP-TRANSMISSIONS/N NJE3149-UP
Group No: 249-7065 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S0509 | 1 BOLT (3/8-16X0.75-IN) | 4 | |
| 3S2093 | 2 STRAP-CABLE | 9 | |
| 1305300 | 3 CLIP | 3 | |
| 1342252 | 4 SENSOR GP-TEMPERATURE (8-VOLT)(TRANSMISSION OIL) | 1 | |
| 2462653 | 5 GUARD AS | 1 | |
| 2497067 | 6 BRACKET | 1 | |
| 3763082 | 7 HARNESS AS-TRANSMISSION | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 4W4293 | PLUG AS-CONNECTOR (17-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 24 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 13 | |
| 8T8737 | PLUG-SEAL | 4 | |
| 9X0145 | RECEPTACLE AS-CONNECTOR (24-PIN) | 1 | |
| 1148843 | SLEEVE-PLASTIC (140-CM) | ||
| 1242911 | BOOT (24-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 3 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 2615510 | BOOT | 4 | |
| 0L1351 | 8 BOLT (3/8-16X0.875-IN) | 2 | |
| 0T0102 | 9 BOLT (3/8-16X0.625-IN) | 2 | |
| 1325789 | 10 CLIP (LADDER) | 2 | |
| 4P7581 | 11 CLIP (LADDER) | 2 | |
| 4P7582 | 12 CLIP (LADDER) | 1 | |
| 4P8134 | 13 CLIP (LADDER) | 1 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 6D5801 | 15 LOCKNUT (8-32-THD) | 4 | |
| 7U4892 | 16 SCREW (8-32X0.75-IN) | 4 | |
| 5P6029 | 17 LOCKWIRE (0.2-M) | ||
| 2147568 | 18 SEAL-O-RING | 1 |
