System And Components
268-4243 BAFFLE GP-RADIATORS/N DLS1-717
Group No: 268-4243 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2684244 | 1 BAFFLE AS | 1 | |
| 0339412 | RIVET | 13 | |
| 0897960 | WASHER (5.3X25X1.6-MM THK) | 13 | |
| 2684249 | STRIP | 1 | |
| 2684245 | 2 BAFFLE AS | 1 | |
| 8T4121 | WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4133 | NUT (M10X1.5-THD) | 6 | |
| 8T4195 | BOLT (M10X1.5X30-MM) | 6 | |
| 0339412 | RIVET | 3 | |
| 0897960 | WASHER (5.3X25X1.6-MM THK) | 3 | |
| 2684250 | STRIP | 1 | |
| 2684246 | 3 BAFFLE AS | 1 | |
| 0339412 | RIVET | 13 | |
| 0897960 | WASHER (5.3X25X1.6-MM THK) | 13 | |
| 2684251 | STRIP | 1 | |
| 2684247 | 4 BAFFLE AS | 1 | |
| 0339412 | RIVET | 13 | |
| 0897960 | WASHER (5.3X25X1.6-MM THK) | 13 | |
| 2684251 | STRIP | 1 | |
| 2758902 | 5 BAFFLE AS | 1 | |
| 6B4594 | RIVET | 5 | |
| 0339412 | RIVET | 9 | |
| 0897960 | WASHER (5.3X25X1.6-MM THK) | 9 | |
| 8T4121 | 6 WASHER-HARD (11X21X2.5-MM THK) | 27 | |
| 8T4137 | 7 BOLT (M10X1.5X20-MM) | 27 |
